Specification
JD Glass product catalogs · Storefront Framing
Aluminum Storefront Systems — Overview & Performance
- 100 Series for 1/4" glass; 200 Series for 1" insulated glass; 200T thermal series for 1" insulated glass
- Screw-spline assembly; identical EPDM gaskets inside and out
- Air infiltration tested per ASTM E283
- Water tested per AAMA 501 / ASTM E331
- Structural tested per ASTM E330 (independent labs; reports on request)
- Door framing components available for all systems
- In-house Class A powder coat and custom colors
Product lines
- 100 Series 1-3/4" × 4-1/2"
- 200 Series 2" × 4-1/2"
- 200T Series 2" × 4-1/2" thermal
Available finishes
SASatin Anodized
DUDark Bronze Anodized
PTCustom Powder Coat
